VA8042 thickness meter,China digital thickness meter,portable thickness meter
- Digital display: 4 digitals
- Measurement range: 0~1200μm.
- Resolution: 1μm.
- Accuracy: ±(3%H+2μm)
- Measurement rate: 0.5 second.
- Display units: μm or mil.
- Critical thickness of metallic base: 1mm. Minimum thickness of metallic base: 0.2mm.
- Minimum curvature radius: protruding 1.5mm, concave 6mm.
- Probe diameter: 13mm.
- Power supply: 7# alkaline cell, 1.5V*3.

features
By electromagnectic method, the meter can measure the coating thickness non-destructively, including paint, spray-plastic, rubber, enamel, or chrome plate, copperizing, aluminum plating on steel, iron, non-austenitic stainless steel.
Four digitals LCD display, differentiating upto μm.
System calibrating by user-self.
Pocket shell, convenient for engineering locale.
Thickness unit “μm”or”mil”optional.
Micro-controller controls, high accuracy.
Coupling state display
Shut down manually or automatically.
Low battery voltage indication.
By electromagnectic method, the meter can measure the coating thickness non-destructively, including paint, spray-plastic, rubber, enamel, or chrome plate, copperizing, aluminum plating on steel, iron, non-austenitic stainless steel.
Four digitals LCD display, differentiating upto μm.
System calibrating by user-self.
Pocket shell, convenient for engineering locale.
Thickness unit “μm”or”mil”optional.
Micro-controller controls, high accuracy.
Coupling state display
Shut down manually or automatically.
Low battery voltage indication.
Specifications
Digital display: 4 digitals.
Measurement range: 0~1200μm.
Resolution: 1μm.
Accuracy: ±(3%H+2μm)
Measurement rate: 0.5 second.
Display units: μm or mil.
Critical thickness of metallic base: 1mm.
Minimum thickness of metallic base: 0.2mm.
Minimum curvature radius: protruding 1.5mm, concave 6mm.
Probe diameter: 13mm.
Power supply: 7# alkaline cell, 1.5V*3.
Resolution: 1μm.
Accuracy: ±(3%H+2μm)
Measurement rate: 0.5 second.
Display units: μm or mil.
Critical thickness of metallic base: 1mm.
Minimum thickness of metallic base: 0.2mm.
Minimum curvature radius: protruding 1.5mm, concave 6mm.
Probe diameter: 13mm.
Power supply: 7# alkaline cell, 1.5V*3.
Payment Methods:
We accept TT bank wire transfer, Western Union, Paypal and escrow payment offered by Alipay Escrow and Escrow.com.
For latter three payment methods, extra charges shall be applied.
Shipping Methods:
To be shipped by express mail, by air or by sea based on customer’s request and weight/volume of goods.
Warranty:
We provide a limited quality warranty of 12 months for the items sold dating from their delivery date.
